Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot

    Buy cheap Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot from wholesalers

    Buy cheap Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot from wholesalers
    • Buy cheap Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot from wholesalers
    • Buy cheap Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot from wholesalers
    • Buy cheap Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot from wholesalers

    Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot

    Ask Lasest Price
    Brand Name : FASEC
    Model Number : Metal light poles
    Certification : ISO9001:2008;CE; 3C
    Price : USD50-USD400 /piece
    Payment Terms : L/C, T/T
    Supply Ability : 50000 pieces per month
    Delivery Time : 30 workdays
    MOQ : 30 pieces
    • Product Details
    • Company Profile

    Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot

    Single Double Arm Street Light Pole Electrical Galvanised Gi 20 Foot 30 Foot 40 Foot 60 Foot

    Street lighting is a critical function that has been largely overlooked in recent years as solar power, LEDs and other technologies have become more popular. You can identify existing street light poles that need repair or replacement and start a business to fix or update them, while also adding solar panels or LED lights. As a trusted and professional manufacturer of custom Steel Structural Supports for Signs, Luminaires, and Traffic Signals, we can do customized production for you, a variety of types of Light, material, and pole height and functions available.


    TECHNICAL SPECIFICATIONS

    TypeStreet Lamp pole, lamp post . Lamp column
    ShapeConoid ,Multi-pyramidal,Columniform,polygonal or conical
    MaterialUsually Q345B/A572,minimum yield strength>=345n/mm2
    Q235B/A36,minimum yield strength>=235n/mm2
    As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52
    Torlance-0.02
    Design Load in Kg300~ 1000 Kg appliced to 50cm from the to pole
    Surface treatmentHot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
    StandardOctagonal tapered column
    Certified by SIRIM QAS INTERNATIONAL.
    Approved by JABATAN KERJA RAYA MALAYSIA.
    Conforms to Standard:
    Pole design : BS EN 40
    Material : BS EN 10025 S275 / JIS G3101 SS400
    Welding : BS 5135
    Galvanizing : BS 729 / ISO 1461 ASTM A 123
    Length of per sectionWithin 14m once forming without slip joint.
    Suit forHighway
    Roadway
    Residential subdivisions
    Commercial development
    OptionHeight from 6m to 12m
    Flange mounted or planted type
    Variable arm length from 0.125m to 3.0m with single or double arm type
    Variable spigot size from 35mm to 60mm.
    Production Process

    Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding

    →Hole drilling →Calibration →Deburr→Galvanization or powder coating ,painting →Recalibration →Thread

    →Packages





    ABOUT US
    We are a professional manufacturer of custom Steel Structural Supports for Signs, Luminaires, and Traffic Signals. Products include but not limited to lighting poles,utility poles, traffic signal poles, telecom towers, roadway sign post and overhead span structures, steel bridges and allied accessories, in assortment of steel grades and production standards. Factory-direct prices for quality products, professional service and on-time delivery, satisfaction and value ensured.

    WHY US?
    • CAD design engineering service - senior engineer team ready to create tailored solutions to fit both your project and budget.
    • Longer product service life - study construction, corrosion resistant finishing and strict quality management.
    • Proven performance - serviced lots of Urban Municipal Projects.
    • Quick shipment - factory ownership, good control of production schedule.


    If you have interest, please contact us for a quote.
